| 圖 片 | 編 號 | 位 置 | 品名尺寸 | 適用機種 | 原廠編號 |
|---|---|---|---|---|---|
 |
MM136 | Upper | 鑽石眼模 Wire Guide 0.105,0.155,0.205,0.255,0.305 |
DWC-MV | X052B662G63/2210004008 X052B662G65/2210004004 X052B662G64/2210004006 X052B662G62/2210004010 |
 |
MM137 | Lower | 鑽石眼模 Wire Guide 0.105,0.155,0.205,0.255,0.305 |
DWC-MV | X052B663G65/2210004005 X052B663G64/2210004007 X052B663G63/2210004009 X052B663G62/2210004011 |
 |
M133 | Lower | 鑽石眼模 Wire Guide 0.105,0.155,0.205,0.255,0.305 |
DWC-HA,SA,SB,SZ,CX, SX,FX,QA,FA,RA, AF2,AF3 |
X052B243G61 X052B243G65 X052B243G62 |
 |
M132 | Upper | 鑽石眼模 Wire Guide 0.105,0.155,0.205,0.255,0.305 |
DWC-HA,SA,SB,SZ,CX, SX,FX,QA,FA,RA, AF2,AF3 |
X053B834G53 X052B834G54 X052B834G56 |
 |
M117 | Upper & Lower |
鑽石眼模 Wire Guide 0.105,0.155,0.205,0.255,0.305 |
DWC-H1,HA,SA,SB | X054D171G54 |
 |
M107 | Upper | 鑽石眼模 Wire Guide 0.105,0.155,0.205,0.255,0.305 |
DWC-J.JA.SA.SB.SZ | X052B054G53 X052B054G54 X052B054G55 |
 |
M103 | Upper & Lower |
鑽石眼模 Wire Guide 0.105,0.155,0.205,0.255,0.305 |
DWC-F,F1,G,H,H',H1,HA,C | X052B040G64 X052B040G65 X052B040G66 |
 |
M140 | Upper | 陶瓷穿線眼模 Ceramic Guide D 12*0.35*33.4L |
DWC-FA-S | X056C082H01 |
 |
M113 | Upper | 鑽石輔助眼模板 0.4mm |
DWC-CX | X056C146G51 |
 |
M135 | Upper | 鑽石螺絲 Sub Die Guide A |
DWC-XC,FX,FA,RA,QA AF2,AF3 |
X054D896G51 |
