| 圖 片 | 編 號 | 位 置 | 品名尺寸 | 適用機種 | 原廠編號 |
|---|---|---|---|---|---|
 |
M405C | Feed Section |
陶瓷出線輪副軸 Pingch Roller φ57*φ19*32t |
DWC-HA,C,SA,SB,SZ,SX | X053C779G51 |
 |
M404C | Feed Section |
陶瓷出線輪主軸 Capstan Roller φ57*φ10*25t |
DWC-H1,C,90CR,90CA, SA,FA10,SK3,AF1,AF2 |
X054D412G51 |
 |
M403C | Feed Section |
陶瓷出線輪副軸 Pingch Roller φ57*φ19*25t |
DWC-H1,C,90CR,90CA, SA,FA10,SK3,AF1,AF2 |
X054D413G51 |
 |
M402C | Feed Section |
陶瓷出線輪主軸 Capstan Roller φ57*φ10*18t |
DWC-F,F1,G,H,H',CX | X054D256G51 X058D077G51 |
 |
M463S | Upper Right Left |
上部夾線輪 Pinch Roller Set 18*10*21 |
DWC-FA-S,BA | X269D013G52 |
|
M463 | Upper Right Left |
上部夾線輪 Pinch Roller Set 14*10*18 |
DWC-FA | X269D013G52 |
 |
M461-2 | Upper Left |
上部陶瓷夾線輪 左顺 Feed Roller Set Clockwise |
DWC-XC,FX,FX-K,SX | X053C522G51+XBRRD-SSL1260 |
 |
M461-1 | Upper Right |
上部陶瓷夾線輪 右逆 Feed Roller Set Counter-Clockwise |
DWC-CX,FX,FX-K,SX | X053C522G51+XBRRD-SSL1260 |
 |
M461 | Upper | 上部陶瓷夾線輪 Feed Roller φ20*16t |
DWC-XC,FX,FX-K,SX | X053C522G51 |
 |
三菱陶瓷惰轮MV 50*19*22 X088D301H04 | 三菱MV机 M452通用 | X088D301H04/2210004711 |
