| 圖 片 | 編 號 | 位 置 | 品名尺寸 | 適用機種 | 原廠編號 |
|---|---|---|---|---|---|
 |
F418B | Feed section |
陶瓷出線主輪 Feed Roller (ceramic) 80Ø*17*22 |
DWC- iD,iE,600iA (Manual)/AWF |
A290-8119-X383 |
|
F407 | Lower | 下機頭引線輪 Lower Roller (ceramic) 38Ø*22Ø*16t |
DWC- 1iD,iE (Manual)/AWF |
A290-8119-X766 |
|
F442-1 | Upper | 陶瓷張力惰輪 Detect Roller (Ceramic) 34Ø*14Ø*8t |
DWC-iD,iE AWF |
A290-8119-X625 |
 |
F414 | Feed section |
陶瓷出線輪 Wire Roller (ceramic) 80Ø*60*18t |
DWC-W(Manual) Pinch+Feed roller |
A290-8101-X707 |
 |
F413 | Feed section |
陶瓷出線主輪 Wire Roller (ceramic) 80Ø*11*24t |
DWC-W2(Manual) Feed roller |
|
|
F412 | Feed section |
陶瓷出線副輪 Wire Roller (ceramic) 80Ø*20*18t |
DWC-W2(Manual) Pinch roller |
|
 |
F406 | Lower | 下機頭引線輪 Lower Roller (ceramic) 38Ø*22Ø*12t |
DWC-A,B,C,iA,iB.iC (Manual)/AWF |
A290-8101-X765 |
|
F405 | Feed section |
陶瓷出線主輪 Feed Roller (ceramic) 40*30w |
DWC-B,series (AWF) |
|
 |
F404 | Feed section |
陶瓷出線主輪 Feed Roller (ceramic) 40*12*32w |
DWC-C series (Manual)/AWF |
A290-8110-X383 |
|
F403 | Feed section |
陶瓷出線副輪 Pinch Roller (ceramic) 40*20*30w |
DWC-C series (Manual)/AW |
A290-8110-X382 |
|
F402-1 | Feed section |
陶瓷出線副輪 Pinch Roller (ceramic) 40*20*18w |
DWC-A,B,series (Manual/AWF) |
A290-8110-Z382 |
 |
F402 | Feed section |
陶瓷出線主輪 Feed Roller (ceramic) 40*12*19w |
DWC-A,B,series (Manual/AWF) |
A290-8110-Z383 |
