| 圖 片 | 編 號 | 位 置 | 品名尺寸 | 適用機種 | 原廠編號 |
|---|---|---|---|---|---|
 |
F406 | Lower | 下機頭引線輪 Lower Roller (ceramic) 38Ø*22Ø*12t |
DWC-A,B,C,iA,iB.iC (Manual)/AWF |
A290-8101-X765 |
 |
F405 | Feed section |
陶瓷出線主輪 Feed Roller (ceramic) 40*30w |
DWC-B,series (AWF) |
|
 |
F404 | Feed section |
陶瓷出線主輪 Feed Roller (ceramic) 40*12*32w |
DWC-C series (Manual)/AWF |
A290-8110-X383 |
|
F403 | Feed section |
陶瓷出線副輪 Pinch Roller (ceramic) 40*20*30w |
DWC-C series (Manual)/AW |
A290-8110-X382 |
|
F402-1 | Feed section |
陶瓷出線副輪 Pinch Roller (ceramic) 40*20*18w |
DWC-A,B,series (Manual/AWF) |
A290-8110-Z382 |
 |
F402 | Feed section |
陶瓷出線主輪 Feed Roller (ceramic) 40*12*19w |
DWC-A,B,series (Manual/AWF) |
A290-8110-Z383 |
|
F401 | Lower | 下機頭引線輪 Wire Sub Roller 49x6.5x6 (Plastic+sus) |
DWC-W | A290-8004-X713 |
 |
F466 | Feed section |
出線副輪軸心 Shaft 37D*99L |
DWC- iA,iB,iC | A290-8112-X378 |
 |
F465 | Feed section |
出線主輪軸心 Shaft 17D*95L |
DWC- iA,iB,iC | A290-8112-X373 |
 |
F464 | Feed section |
出線主輪軸心 Shaft 12D*85L |
DWC-C | A290-8110-X373 |
 |
F463 | Lower | 引線輪軸心 Shaft 10D*24L |
DWC- C,iA,iB,iC | A290-8110-X766 |
|
F462 | Lower | 引線輪軸心 Shaft 10D*31L |
DWC-A,B,series | A290-8101-X766 |
